BDC-S1210-8P
This is an 8-port PoE switch that is optimized for small home and office networks. It can power a variety of devices such as IP phones, security cameras, and wireless access points. It has 10/100 Mbps PoE ports with a Gigabit uplink and SFP port.
Description
The BDCOM S1200 Series is a 1000M uplink smart POE switch with a large buffer memory introduced by BDCOM. It is designed for the video surveillance and wireless coverage in the medium and small networks. BDCOM S1200 Series has three models: S1210-8P, S1218-16P, and S1226-24P, which meets the need of networks of different scales.
The BDC-S1210-8P is an affordable PoE+ switch that provides power for up to eight security cameras, with a Gigabit uplink port for connecting to the rest of your network.
Key Features
- 8* 100M PoE+ ports
- 1* Gigabit uplink port
- 1* Gigabit SFP port
- Built-in AC power supply
- Functional dip switch:
Default–standard working mode
CCTV–1~8 port extension
VLAN –1~8 port isolation
Ports & Capacity
Connectivity Diagram
BDCOM PoE switches are optimized for CCTV applications. Depending on the number of PoE ports available, you can connect a large number of IP cameras, phones, or access points to your network.
Download
- BDCOM-S1200 Series Datasheet
- Hi-Res Photos (Front / Back)
