Technical Specification |
Master Processor |
SOC |
HI3518E V300 |
Image Sensor |
Sensor |
1/3″ color CMOS Sensor, 2-megapixel |
Visual angle |
H (horizontal) 95 degrees; V (vertical) 55 degrees; D (diagonal) 110 degrees |
Minimum Illumination |
0.01 Lux |
Audio |
Input/Output |
Two-way voice intercom available (built-in Microphone and speaker) |
Audio Compressing Method |
AAC |
Video |
Video Compressing Method |
H.265 (support H.264, H.265) |
Lighting Frequency |
50Hz, 60Hz |
Image Frame Rate |
15 fps(Max 30fps) |
Maximum Image Resolution |
1920*1080P |
Light Source for Night Vision |
IRCUT double optical filter automatic switching, and 8 infrared lights (850nm wavelength)Irradiation distance: 7M |
Network |
Wireless Network |
2.4G Wi-Fi (IEEE802.11b/g/n), built-in antenna |
Protocols Supported |
TCP/IP, UDP/IP, DHCP, RTMP, MUTP |
IP Address Supported |
Dynamic IP address supported |
AI |
Intelligent Features |
Human contour detection, activity zone,intelligent push, pet snapshot |
Alarm Notification |
Alarm Methods |
Alarm push by mobile APP, alarm sound |
Wake-up |
Wake-up Method |
PIR body induction wake-up, and remote positive wake-up |
Video Recording |
Recording Method |
Alarm triggered recording, and manual recording |
Video Storage |
Cloud storage, local Micro SD card, and mobile phone memory |
Indicator Lamps |
LED Indicator |
RGB tri-color lamp indicating the status of power/network signal/functionality |
Battery |
Capacity |
18650*2 ; 5200mAh/6700mAh |
Removability |
Unremovable |
Battery Life |
6 months (provided that 20 10s videos are recorded per day) |
Standby Time |
1 year |
Charging Voltage |
DC 5V/1.5A(Micro USB) |
Charge Time |
< 8 hours |
Protection Method |
IP65 resistance to dust and water;over-current/over-discharge/over-charge/short circuit/charging protection at high & low temperatures |
Interfaces |
Power Supply |
1 Micro USB interface |
SD Card |
1 Micro SD card (up to 128GB supported) |
Keys |
1 reboot key and 1 on/off key |
Installation Method |
Installation Method |
Magnet and 1/4 universal screw holes |
Environment |
Dustproof and waterproof |
IP65 |
Operating Environment |
-10° ~ 45°C /10% ~ 80% (no condensation) |
Storage Environment |
-20°C ~ 60° /0% ~ 90% (no condensation) |
Specifications |
Size (LxWxH) |
58mm*84mm*91mm(with bracket excluded) |
Net Weight of Bare Machine |
Approx. 267g |
Finished weight |
Approx. 500g |
Material + Process |
ABS |
Color |
White with high gloss |
Certifications |
Certificate |
RoHS,CE,FCC,WEEE,MSDS,UN38.3,IPX6 |
APP |
VicoHome |
