MZE-PB55B
This is a stainless-steel push to open switch for creating accessible doors and entrances. This button is 4.5″ wide, making it suitable for installation on a double-gang junction box. These are heavy-duty buttons, designed to last for years in a commercial environment.
Description
The PB55B all-active push switch is built for reliable performance in demanding commercial and institutional environments. Constructed with a brushed stainless steel faceplate, it combines durability with a professional appearance.
Designed for standard double-gang electrical boxes, the unit comes preassembled for fast installation to in-wall or surface-mount boxes using tamper-resistant Allen screws and the included hex key.
Its two-piece modular design allows the rear assembly to mount first, with the faceplate secured afterward—making field maintenance or replacement simple and efficient.
Specification
| Switch Type: |
Momentary
|
| Contact Type: |
COMMON / N.O. /N.C.
|
| Current Rating: |
15 A @ 250 VDC
|
| Mounting: |
Double Gang
|
| Dimensions: | 4-1/2″ x 4-1/2″ x 1-37/64″ (114mm x 114mm x 40mm) |
