MZE-MRB201B
This is a mushroom style push-to-exit switch with a highly visible red button. The narrow width of 1.75″ makes it suitable for installation on tight door frames or other compact areas. The aluminum faceplate offers exceptional clarity and the blue ‘push to exit’ wording is clearly visible.
Description
The MRB201B is a heavy-duty mushroom push switch engineered for high-demand access control applications in public and commercial environments.
It features a vibrant red 1-5/8″ diameter actuator and a 1/4″ thick aluminum faceplate for exceptional durability.
Its compact 1-3/4″ narrow profile makes it ideal for door frames or tight installation areas.
The bayonet-style interlocking design allows tool-free front assembly without set screws, simplifying installation and maintenance.
The switch is modular and supports spring return operation.
Specification
| Switch Type: |
Momentary
|
| Contact Type: |
COMMON / N.O. /N.C.
|
| Current Rating: |
2 A @ 36 VDC, 3A @ 220 VAC
|
| Mounting: |
Narrow (Jamb)
|
| Dimensions: | 1-3/4″ x 4-1/2″ x 2-11/64″ (44mm x 114mm x 55mm) |
