LYS-LS2-48GT4SFP-P

This is a 48-port managed PoE switch with four SFP ports. It supports PoE+ on all 48-ports, with a total PoE budget of 370 W. It also has advanced layer-2 features such as VLAN configuration, DHCP snooping, STP (spanning tree protocol) and rebooting individual PoE ports.

Note: This product is not available yet. It’s scheduled to arrive in June 2026.

Login for pricing
Categories: , Tags: , ,

Description

The Lysora LS2-48GT4SFP-P is a 48-port managed PoE switch with a 370 W PoE budget. You can manage it remotely through the Lysora Cloud Portal, letting you reboot individual ports and monitor the PoE usage of each port.

This is an advanced layer-2 switch, with an larger packet buffer, improved switching capacity, and better forwarding rate compared with the Lysora LCS series switches. This is basically an enterprise-level switch, built to handle whatever type of traffic you throw at it.

This switch also supports the following features:

  • DHCP Snooping – Set certain ports as trusted, which means only devices on those ports can assign DHCP addresses to the rest of your network (improves security).
  • Loop Prevention – Block the signal from any ports that are looped, preventing the network from crashing.
  • Long-distance PoE – Allows you to connect a device up to 250 m (820 ft), but lowers the speed of the port to 10 Mbps.
  • PoE Watchdog – Will automatically reboot the PoE port if no traffic is detected after 90 – 1800 seconds (adjustable).
  • STP (spanning tree protocol) – Supports STP, RSTP, and MST for automatic failover, improving network redundancy.
  • Packet Capture & Detailed Syslog – Run packet captures directly on the switch, giving you flexibility for troubleshooting network issues.

Features – 48-Port Layer 2 Managed PoE Switch with 370 W PoE Budget

  • 48-Port 10G L2 Managed PoE Switch
  • 48 Gigabit RJ45 PoE/PoE+ Ports
  • 4 *1G SFP Slots
  • 370W PoE Power budget
  • 19-inch Rack-mountable Steel Case

Specification

General Specifications
Product Model LS2-48GT4SFP-P
Device Description 48-Port Cloud Managed PoE Switch with 370 W PoE Budget
Dimensions 440 mm x 293 mm x 44 mm (17.32 in. x 11.54 in. x 1.73 in.)
Weight 5.86 kg (12.92 lbs)(with packaging materials), 4.32 kg (9.52 lbs) (without packaging materials)
Enclosure Material Metal
Mounting Rack/Desk
Warranty 3 years
Hardware & Performance
1GbE RJ45 Ports 48
1G SFP Ports 4
PoE/PoE+ Out Ports 48
Switching Capacity 104 Gbps
Forwarding Rate 77.38 Mpps
MAC Address Table 16,000 entries
Jumbo Frame (MTU) 9216 bytes
MTBF 400,000 hours
Power & Environment
PoE Budget 370 W
Max. Power Consumption 46 W (with no PoE load), 450 W (with PoE full load)
Operating Temperature 0°C to 50°C (32°F to 122°F)
Cooling 2 × Fixed fans, side-to-rear airflow
Management & Compliance
Management Options Cloud, App, Web GUI and CLI management
PoE Watchdog Yes
NDAA Compliant Yes
Certifications FCC, IC, cTUVus
