LYS-L7-T
This is a Wi-Fi 7 AP with IP65 weather resistance and a 2.5 GbE port. It has 5 spatial streams, supports 110+ simultaneous users, and has a maximum distance of up to 300 m (984 ft).
Note: This product is not available yet. It’s scheduled to arrive in June 2026.
Description
The Lysora L7 is an outdoor Wi-Fi 7 AP, designed for medium-density applications. It supports 110+ users, with a maximum bandwidth of 5011 Mbps between the 2.4 GHz and 5.8 GHz channels. There are 5 spatial streams with a max transmission distance of up to 300 m (984 ft).
This access point can be powered via PoE+ and consumes up to 30 W of power. You can manage it remotely through the Lysora Cloud Portal – allowing you to configure the SSID(s) and other settings for your customer before installation.
Features –Wi-Fi 7 BE5040 Dual-Band Outdoor Access Point
- Wi-Fi 7 BE5000 dual-band outdoor access point
- Up to five spatial streams
- 1 x 100/1000/2500BASE-T port
- Unified networking and management based on Lysora Cloud App
- Max power consumption < 18 W
- 802.3af/at PoE In
Specification
| Overview | |
| Dimensions | 90 mm x 46 mm x 239 mm (3.54 in. x 1.81 in. x 9.41 in.) |
| Weight | ≤ 0.7 kg (1.54 lbs.) (without packaging materials) |
| Coverage Area | 5 GHz max: 300 m (984.25 ft.) 2.4 GHz max: 100 m (328.08 ft.) 5 GHz recommended: 150 m (492.13 ft.) 2.4 GHz recommended: 50 m (164.04 ft.) Note: The data is obtained in an ideal environment without obstruction. The signal coverage radius depends on client performance and environmental interference. |
| Mounting Type | Wall, Pole (Mounts Included) |
| Hardware & Networking | |
| Networking Interface | (1) 2.5GbE RJ45 port |
| Wi-Fi Standards | IEEE 802.11 a/b/g/n/ac/ax/be (Wi-Fi 5, Wi-Fi 6, & Wi-Fi 7) |
| Antenna Gain | 2.4 GHz: 3.62 dBi, 5 GHz: 6.28 dBi |
| Max. Transmit Power | 2.4 GHz: 26 dBm, 5 GHz: 26 dBm |
| LED | 1 × System Status LED (blue) |
| Button | 1 × Factory Reset Button |
| Wireless Performance | |
| Max Wireless Data Rate | 2.4 GHz: 688 Mbps, 5 GHz: 4323 Mbps |
| Max. Client Count | 110+ simultaneous clients |
| MIMO | 2.4 GHz: 2 x 2 MU-MIMO, 5 GHz: 3 x 3 MU-MIMO |
| Spatial Streams | 5 |
| Power Specifications | |
| Power Consumption | ≤ 21 W |
| Power Method | PoE+ |
