LYS-LR1500XS

This is a high-performance router with 4 x Gigabit ports, 4 x 2.5 Gigabit ports, and 2 x 10 Gigabit SFP+ ports. It’s capable of handling 1500 concurrent users and has built-in support for VPN protocols such as WireGuard and OpenVPN.

Product Overview

The Lysora LR1500XS is a high-performance router with four 2.5 Gigabit ports and four regular Gigabit ports (8 × RJ45 ports in total). It also has two 10 Gigabit SFP+ ports, allowing you to transfer data extremely quickly. For locations with hundreds of clients, this router will chew through packets like no there’s no tomorrow.

It also supports popular VPN protocols such as OpenVPN and Wireguard, allowing you to connect to your home or office network securely from a remote location.

As with all Lysora products, you can manage it remotely through the Lysora Cloud Portal.


The Lysora Cloud Portal allows you to manage your network easily from anywhere.

Features – 8-Port (4 x 2.5G Ports) High-Performance Cloud Managed Router with 2 x SFP+ Ports

  • Rack-mountable 10-port router, providing one 2.5G WAN port, one 1G LAN port, three 2.5G LAN/WAN ports, three 1G LAN/WAN ports, one SFP+ port and one 1G/2.5G/10G SFP port
  • Recommended 1500 concurrent connections, maximum 4 Gbps throughput
  • Cloud remote management supported

Specification

General Specifications
Product Model LR1500XS
Device Description 10-Port High-Performance Cloud Managed Router with 4 x 2.5G Ports and 2 x SFP+ Ports
Dimensions 440 mm x 210 mm x 43.6 mm (15.75 in. x 8.27 in. x 1.72 in.)
Weight 3.82 kg (8.42 lbs) (with packaging materials), 3 kg (6.61 lbs) (without packaging materials)
Enclosure Material Metal
Mounting Desktop Mounting
Warranty 3 years
Hardware & Performance
1GbE RJ45 Ports 4 x (plus 4 x 2.5G RJ45 ports)
10G SFP+ Ports 2 x 10GE SFP+ ports
PoE/PoE+ Out Ports –
Recommended number of clients 1500 clients
Throughput 4000 Mbps
VPN Support L2TP, PPTP, OpenVPN, IPsec, WireGuard, L2TP over IPsec, SD-WAN
CPU Quad-core processor, 1.8 GHz clock frequency per core
Power & Environment
PoE Budget –
Max. Power Consumption 18 W
Operating Temperature 0°C to 40°C (32°F to 104°F)
Cooling Fanless design / Natural cooling
Management & Compliance
Management Options Cloud, App, and Web management
SSH & Telnet No
NDAA Compliant Yes
Certifications FCC, IC, cTUVus
