LR1500XS

This is a high-performance router with 4 x Gigabit, 4 x 2.5 Gigabit, and 2 x 10 Gig SFP+ ports. It’s capable of handling 1500 concurrent users and has built-in support for VPN protocols such as WireGuard and OpenVPN.

Product Overview

The Lysora LR1500XS is a high-performance router with four 2.5 Gigabit ports and four regular Gigabit ports (8 × RJ45 ports in total). It also has two 10 Gigabit SFP+ ports, allowing you to transfer data extremely quickly. For locations with hundreds of clients, this router will chew through packets like there’s no tomorrow.

It also supports popular VPN protocols such as OpenVPN and WireGuard, allowing you to connect to your home or office network securely from a remote location.

As with all Lysora products, you can manage it remotely through the Lysora Cloud Portal.


The Lysora Cloud Portal allows you to manage your network easily from anywhere.

Features – 8-Port (4 x 2.5G Ports) High-Performance Cloud Managed Router with 2 x SFP+ Ports

  • Rack-mountable 8-port router, providing four 2.5G ports, four 1G ports, and two SFP+ (10 G) ports.
  • Recommended 1500 concurrent users, maximum 4 Gbps throughput
  • Cloud remote management supported

Specification

General Specifications
Product Model LR1500XS
Device Description 10-Port High-Performance Cloud Managed Router with 4 x 2.5G Ports and 2 x SFP+ Ports
Dimensions 440 mm x 210 mm x 43.6 mm (17.32 in. x 8.27 in. x 1.72 in.)
Weight 3.82 kg (8.42 lbs) (with packaging materials), 3 kg (6.61 lbs) (without packaging materials)
Enclosure Material Metal
Mounting Desktop Mounting (2 x rack-mount brackets included)
Warranty 3 years
Hardware & Performance
2.5GbE RJ45 Ports 4
1GbE RJ45 Ports 4
10G SFP+ Ports 2
Port Roles 1 fixed LAN, 1 fixed WAN, 8 configurable LAN/WAN (max 9 LAN or 9 WAN)
PoE/PoE+ Out Ports N/A (non-PoE model)
Recommended number of clients 1500 concurrent clients
Throughput 4000 Mbps
Concurrent Sessions 300,000
VPN Support IPsec, WireGuard, OpenVPN, L2TP, L2TP over IPsec, PPTP, SD-WAN
CPU Quad-core processor, 1.8 GHz clock frequency per core
Memory & Storage 4 GB RAM, 128 MB flash, 8 GB eMMC, 1 x SATA 3.0 HDD bay
Power & Environment
PoE Budget N/A (non-PoE model)
Max. Power Consumption 18 W
Operating Temperature 0°C to 40°C (32°F to 104°F)
Cooling Fanless design / Natural cooling
Management & Compliance
Management Options Cloud, App, and Web management
Key Features BGP, OSPFv2/OSPFv3 and RIP dynamic routing; IPv4/IPv6 policy-based routing and URL-based routing; WAN load balancing; 500 IPv4 / 500 IPv6 static routes; AC mode with management for up to 1000 APs; local and cloud portal authentication with 802.1X and MAB; user behavior management, application control and traffic audit
SSH & Telnet No
NDAA Compliant Yes
Certifications FCC, ISED, cTUVus, TEC
