PW-POE-30
Outdoor PoE Splitter | 1 port 100M PoE Input Port + 2 port 100M PoE Output Port | Support IEEE802.3af/t
Description
Features – PoE Extender and Splitter
- 1 port 100M PoE input port + 2 Port 100M PoE Output
- Ideas for adding extra IP Camera with Existing Cable Run
- Support multiple cam (upto 3) with one existing cable
- No additional power required
- Operating temperature: -20 °C to 55 °C
- PoE supply power 30W (IEEE802.3af/at)
- Extend 100M
Specification
| Model | PW-POE-P30 |
| Description | Cascade PoE transmission |
| RJ45 port | 1 port 100M PoE Input Port +2 port 100M PoE Output Port |
| Network Standard | IEEE 802.3 、IEEE 802.3u、IEEE 802.3* 、IEEE802.3af/at |
| Transmission medium | 8 core cat5 cable and above unshielded twisted wire（≤100m） |
| Indicator light | Power indicator (yellow light), LINK indicator (green light) |
| Network capability | MAC address: 4K, bandwidth:0.6Gbps |
| Input Power | 1236 standard PoE supply power 30W (IEEE802.3af/at) |
| Size & Package | 123mm*91mm*24mm |
| Use environment | Operating temperature: -20 ° C to 55 ° C Storage temperature: -40 ° C to 70 ° C |
| Application | IPC installation, PoE switch expansion, network cable extension |
