IPC2128SR3-DPF60

8MP Mini-bullet IP Camera, IR up to 30m, IP67, Fixed 6.0mm lens

Discontinued: Replaced by updated model IPC2128SR5-ADF40KM-G

Category: Tags: , ,

Description

Uniview IPC2128SR3-DPF60 is an excellent choice for commercial security. At full 8MP resolution, this camera will provide the most detail of a scene with sufficient lighting. Additionally, built-in IR provides illumination up to 30m in very dark environments.

The 6.0mm lens provides a narrower field of view with a higher pixel density.

Features – 4K Mini Fixed Bullet Network Camera

  • Day/night functionality
  • SmartIR, up to 30m (98ft) IR distance
  • Optical glass window with higher light transmittance
  • IR anti-reflection window to increase the infrared transmittance
  • 2D/3D DNR (Digital Noise Reduction)
  • Up to 120dB WDR (Wide Dynamic Range
  • Ultra 265,H.265, H.264, MJPEG
  • Triple streams
  • 9:16 corridor format
  • ONVIF Conformance
  • Wide temperature range: -30°C ~ 60°C (-22°F ~ 140°F)
  • Wide voltage range of ±25%
  • IP67
  • 3-Axis

Specification

IPC2128SR3-DPF40 IPC2128SR3-DPF60
Camera
Sensor 1/2.5″, 8.0 megapixel, progressive scan, CMOS
Lens 4.0mm@F2.0 6.0mm@F2.0
DORI Distance Lens (mm) Detect(m) Observe(m) Recognize(m) Identify(m)
4.0 72 28.8 14.4 7.2
6.0 108 43.2 21.6 10.8
Angle of View(H) 91.6° 54.2°
Angle of view(V) 47.2° 32.5°
Angle of view(O) 112.7° 66.7°
Adjustment Range Pan: 0°~360° Tilt: 0° ~ 90° Rotation: 0° ~ 360°
Shutter Auto/Manual, 1~1/100000s
Minimum Illumination Colour: 0.05Lux (F2.0, AGC ON)
0Lux with IR on
Day/Night IR-cut filter with auto switch (ICR)
S/N >52dB
IR Range Up to 30m (98ft) IR range
wavelength 850nm
IR On/Off Control Auto/Manual
Defog Digital Defog
WDR 120dB
Video
Video Compression Ultra 265,H.265, H.264, MJPEG
H.264 code profile Baseline profile, Main Profile, High Profile
Frame Rate Main Stream:8MP (3840*2160), Max 20fps;
Sub Stream:1080P (1920*1080), Max 30fps;
Third Stream:D1(720*576), Max30fps
Video Bit Rate 128 Kbps~16 Mbps
9:16 Corridor Mode Supported
OSD Up to 8 OSDs
Privacy Mask Up to 8 areas
ROI Up to 8 areas
Motion Detection Up to 4 areas
White Balance Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
Digital noise reduction 2D/3D DNR
Smart IR Support
Flip Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise
Dewarping Support
HLC Support
BLC Support
Network
Protocols IPv4,IGMP,ICMP,ARP,TCP,UDP,DHCP, RTP,RTSP,RTCP,DNS,DDNS,NTP,FTP,UPnP,HTTP,HTTPS,SMTP, SSL,QoS
Compatible Integration ONVIF(Profile S, Profile T), API
Client EZStation
EZView
EZLive
Web Browser Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below
Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+
Interface
Network 1 RJ45 10M/100M Base-TX Ethernet
Certifications
Certifications CE: EN 60950-1
UL: UL60950-1
FCC: FCC Part 15
General
Power DC 12V±25%, PoE (IEEE 802.3af)
Power consumption: Max 8W
Dimensions (L × W × H) 191.3×72.6×70.9mm (7.5”×2.9”×2.8”)
Net Weight 0.5kg (1.1lb)
Material Metal
Working Environment -30℃ ~ 60℃ (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
Strorage Environment -30℃ ~ 60℃ (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
surge protection 2KV
Ingress Protection IP67
