RE606M
Wireless Tilt Sensor, for Overhead Garage Doors & Windows, Screw Mounting (not included), ~10 Year Battery Life
Description
Features – RE606M Tilt Sensor, Connect+™ Encrypted
- New, high accuracy MEMS sensor
- Industry-leading wireless range and battery life
- Secure encrypted wireless transmissions
Specification
| Physical | |
| Housing Dimensions
Weight with Battery Mounting Fastener Cover-Securing Screw (optional, not provided) |
3.25 x 1.40 x 1.05 inches (8.3 x 3.6 x 2.7 cm)
1.90 ounces (54 grams) #4 or #6 screws (not provided) Pan Head, #1 x .25 inches, A/AB Thread Forming (sheet metal) screw, McMaster 90190A051 |
| Environmental | |
| Operating Temperature
Maximum Humidity |
0 to 120 °F (-18 to 49 °C)
85% non-condensing relative humidity |
| Sensor Specifications | |
| Frequency
Replacement Battery Battery Life Battery Voltage Current Draw Transmitted Indications |
433.92 MHz
One Panasonic CR123A 10 to 15 years 3.0 VDC (Nominal), 2.2 VDC (Low) 20 mA (Maximum), 0.6 uA (Quiescent) Cover Tamper, Low Battery, Supervision |
| Certification | |
| RE606M | FCC, IC |
