RE607
Outdoor Wireless Door/Windows Contact, Screw Mounting (not included), 2x External Contact Connections, IP67 Weatherproof, ~10 Year Battery Life
Description
Features – Outdoor Door/Window Sensor, Connect+™ Encrypted
- Industry-leading wireless range and battery life
- Wide magnetic gap distance
- Two built-in external contact zones
- Secure encrypted wireless transmissions
- IP67 waterproof enclosure rating
- 5-year warranty
Specification
| Physical | |
| Housing Dimensions
Weight with Battery Mounting Fasteners Removal Tamper Fastener |
3.3 x 1.3 x 2.8 inches (8.4 x 3.3 x 7.1 cm)
5.7 ounces (161.6 grams) Four 1 inch stainless steel screws (provided) One 11/4 inch stainless steel screw with rubber washer (provided) |
| Environmental | |
| Operating Temperature
Maximum Humidity Ingress Protection Rating |
-40° to 158°F ( -40° to 70°C)
100% Relative Humidity (RH) IP67 |
| Sensor Specifications | |
| Frequency
Replacement Battery Nominal Battery Life Battery Voltage Current Draw Transmitted Indications Max Wire Length on External Contacts |
433.92MHz
One Panasonic® CR123A Lithium Battery 10 years 3.0 VDC (Nominal), 2.2 VDC (Low) 20 mA (Maximum), 0.6 uA (Quiescent) Cover Tamper, Removal Tamper, Low Battery, Supervision 7.5 feet |
| Certification | |
| RE607 | FCC, IC |
