RE663

Alula Wireless LED Keypad, 24V AC power input, Optional AA battery backup (~1-year battery life), Coloured LED for Arming Status

Description

Features – Alula LED Keypad, Connect+™ Encrypted

  • Displays real-time status
  • Wall or table mount
  • AC with battery backup or battery only power
  • 1 year battery life for battery only power
  • User replaceable AA batteries

Specification

Physical
Wall Dimensions

Table Top Footprint

Weight

Mounting Fasteners

Pilot Hole for Screw into Wood

Pilot Hole for Wall Anchor

3.81 x 5.10 x 1.55 inches (9.68 x 12.94 x 3.94 cm)

3.81 x 5.47 x 3.17 inches (9.68 x 13.89 x 8.05 cm)

1.49 lb (675 g)

#6 screws & 2 wall anchors (included)

Ø 1/8 in (3 mm)

Ø 3/16 in (4.7 mm)

Environmental
Operating Temperature

Maximum Humidity

32 to 120°F (0 to 49°C)

85% relative humidity non-condensing

Device Specifications
Frequency

Power Supply

Input

Output

Part Number

Replacement Battery

Nominal Battery Life

Current Draw

Transmitted Indications

2.4 GHz

100-240VAC, 50/60Hz, 0.5A

12VDC, 1A

RE012-6

4 AA batteries

1 year (Battery only operation under normal use)

350mA (Maximum)

Low Battery, Supervision, Tamper, AC Fail

Certification
RE663 FCC, IC
