The underside of an outdoor Reyee WiFi 6 access point

RG-RAP6262

This is a Wi-Fi 6 outdoor AP with weatherproof IP68 protection. It has a powerful omni-directional antenna for long range coverage, and supports up to 500 simultaneous clients. It powers up via PoE+, supports fiber optic connection, and includes a bracket for wall mounting. You can manage the device through the Ruijie Reyee app, including remotely through the cloud.

Description

The Reyee RAP6262 is an outdoor Wi-Fi 6 access point designed for school campuses, plazas, parks, and more. It’s IP68 weather resistant and designed for temperatures as low as -30°C, perfect for cold Canadian weather! It supports up to 512 simultaneous users, but we recommend not more than 110 users for optimal performance.

This device can be managed remotely using the Ruijie Reyee app on your phone. Simply connect the RAP6262 to your network, scan the QR code on the back of the device, and click add within the Reyee app. There’s also a 3-year warranty should anything happen to the device within that timeframe.

Highlight Features

  • UFO-style design – perfect blend of high performance and full coverage.
  • Wi-Fi 6 ultra-high-speed.
  • Long-distance deployment with optical ports.
  • IP68 rating, adapting to harsh environments.
  • Powers via PoE+ 48V (IEEE 802.3at) or 12V/2A DC
  • Easily adding extra outdoor Wi-Fi with Reyee mesh.
A spherical outdoor wireless access point with text above reading 'Perfect Blend of High Performance and Full Coverage'. A spherical outdoor wireless access point with text above reading 'Wi-Fi 6 Ultra-High-Speed.'

Specification

RG-RAP6262
Wireless Protocol 802.11ax (Wi-Fi 6), 2.97Gbps
Network Port 1 x 10/100/1000 Base-T, 1 x 1GBase-X SFP
Antenna High gain omni-directional antenna
MIMO 2×2 @2.4 GHz, 2×2 @5 GHz
Maximum / Recommended Clients Up to 512 clients / Recommended up to 110 clients
Operating Temperature -30°C to 65°C
Dimensions 230 mm x 230 mm x 195 mm (excluding mounting bracket)
Weight 1.4 kg (excluding mounting bracket)
Power Supply 802.3at PoE, 12V/2A DC Adaptor
Power Consumption ≤24 watts
Certifications CE, ROHS, UKCA, EAC
Warranty 3 Years
