| Model |
IPC816SB-ADF16KMC-I1 |
| Camera |
| Max Resolution |
6 MP |
| Sensor |
1/2.5″ CMOS |
| Min. Illumination |
Color: 0.005 Lux (F2.0, AGC ON), 0 Lux with IR |
| Day/Night |
IR-cut filter with auto switch (ICR) |
| Shutter |
Auto/Manual, 1 to 1/100000 s |
| S/N |
> 52 dB |
| WDR |
120 dB |
| Lens |
| Focal Length |
1.6 mm |
| Iris Type |
Fixed |
| Field of View (H) |
180 ° |
| Field of View (V) |
180 ° |
| Field of View (D) |
180 ° |
| Iris |
F2.0 |
| Lens Type |
Fixed |
| DORI |
| DORI Distance (Lens) |
1.6 mm |
| DORI Distance (Detect) |
36.0 m (118.1 ft) |
| DORI Distance (Observe) |
14.4 m (47.2 ft) |
| DORI Distance (Recognize) |
7.2 m (23.6 ft) |
| DORI Distance (Identify) |
3.6 m (11.8 ft) |
| Illuminator |
| Illumination Distance (IR) |
15 m (49.2 ft) |
| Supplemental Light |
IR |
| IR On/Off Control |
Auto/Manual |
| Wavelength |
850 nm |
| Video |
| Main Stream |
Fisheye View: 6 MP (2560 × 2560), max. 30 fps; 2048 × 2048, max. 30 fps; 1440 × 1440, max. 30 fps;
Panorama View: 6 MP (2560 × 2560), max. 30 fps; 2048 × 2048, max. 30 fps; 1440 × 1440, max. 30 fps;
PTZ View: 1920 × 1080, max. 30 fps |
| Sub Stream |
Fisheye View: 1024 × 1024, max. 30 fps |
| Video Compression |
Ultra 265, H.265, H.264, MJPEG |
| Third Stream |
Fisheye View: D1 (720 × 576), max. 30 fps; CIF (352 × 288), max. 30 fps |
| H.264 Code Profile |
Baseline profile, Main profile, High profile |
| Video Bit Rate |
128 Kbps to 16 Mbps |
| U-code |
Support |
| OSD |
Up to 8 OSDs |
| Privacy Mask |
Up to 4 areas |
| ROI |
Up to 8 areas |
| Video Stream |
Octuple Streams |
| Live View Display |
| Hardware Decoding |
Ceiling mount: fisheye view, fisheye + 4PTZ, horizontal panorama view, vertical panorama view
Table mount: fisheye view, fisheye + 4PTZ, horizontal panorama view, vertical panorama view
Wall mount: fisheye view, fisheye + 4PTZ, panorama view |
| Software Decoding |
Ceiling mount: fisheye view, 360° panorama + 1PTZ, 180° panorama view, fisheye + 3PTZ, fisheye + 4PTZ, fisheye + 8PTZ, 360° panorama + 6PTZ
Table mount: fisheye view, 360° panorama + 1PTZ, 180° panorama view, fisheye + 3PTZ, fisheye + 4PTZ, fisheye + 8PTZ, 360° panorama + 6PTZ
Wall mount: fisheye view, 180° panorama view, 180° panorama view + 3PTZ, 180° panorama view + 4PTZ, 180° panorama view + 8PTZ |
| Image |
| White Balance |
Auto, Outdoor, Fine tune, Sodium lamp, Locked, Auto2, Area white balance |
| Digital Noise Reduction |
2D/3D DNR |
| Smart IR |
Support |
| Flip |
Normal, Flip vertical, Flip horizontal, 180° |
| Dewarping |
N/A |
| HLC |
N/A |
| BLC |
Support |
| Defog |
Digital defog |
| Image Stabilization |
N/A |
| Intelligent |
| Smart Intrusion Prevention |
Cross line detection, intrusion detection (support false alarm filtering and the classification of human, non-motor vehicle and vehicle) |
| People Counting |
Support people flow counting and crowd density detection |
| Statistical Analysis |
Heat map (Working with management platform) |
| Events |
| Basic Detection |
Motion detection, Ultra motion detection, Tampering alarm, Audio detection |
| General Function |
Watermark, IP address filtering, Access policy, ARP protection, RTSP authentication, User authentication, HTTP authentication, Alarm input, Alarm output |
| Audio |
| Audio Compression |
G.711U, G.711A, AAC-LC |
| Audio Bitrate |
G.711U/G.711A: 64 kbps, AAC-LC: 128 kbps |
| Two-way Audio |
Support |
| Suppression |
Support |
| Sampling Rate |
G.711U/G.711A: 8 kHz, AAC-LC: 8 kHz, 16 kHz, 48 kHz |
| Storage |
| Edge Storage |
MicroSD, up to 512 GB |
| Network Storage |
ANR, NAS (NFS) |
| Network |
| Protocols |
IPv4, IPv6, IGMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, ICMP, SSL/TLS |
| Compatible Integration |
ONVIF (Profile S, Profile G, Profile T, Profile M), SDK, API |
| User/Host |
Up to 32 users. 3 user levels: administrator, common user and operator |
| Security |
Password protection, Strong Password, HTTPS encryption, Export operation logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, WSSE and Digest Authentication for ONVIF, TLS 1.2 |
| Client |
EZStation, APP |
| Interface |
| Audio I/O |
1 Input: impedance 35 kΩ, amplitude 2 V [p-p], 1 Output: impedance 600 Ω, amplitude 2 V [p-p] |
| Alarm I/O |
1/1 |
| Serial Port |
N/A |
| Built-in Mic |
Built-in dual-mic |
| Built-in Speaker |
Support |
| Network |
1 × RJ45 10 M/100 M Base-TX Ethernet |
| Video Output |
N/A |
| Certification |
| EMC |
CE-EMC (EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 50130-4)
FCC (FCC 47 CFR part15 B) |
| Safety |
CE-LVD (EN 62368-1)
UL/CUL (UL 62368-1, CAN/CSA C22.2 No. 62368-1) |
| Environment |
CE-RoHS (2011/65/EU ; (EU) 2015/863) ; WEEE (2012/19/EU) |
| Protection |
IP67 (IEC 60529)
IK10 (IEC 62262) |
| General |
| Power |
DC 12 V±25%, PoE (IEEE 802.3af) |
| Power Consumption |
Max. 8.4 W |
| Power Interface |
Ø5.5 mm coaxial power plug |
| Dimensions |
Ø126 mm × 52 mm (Ø5.0″ × 2.1″) (Ø × H) |
| Weight |
0.44kg （0.97lb） |
| Material |
Metal + Plastic |
| Working Environment |
-30 ℃ to 60 ℃ (-22 ℉ to 140 ℉), Humidity: ≤ 95% RH (non-condensing) |
| Storage Environment |
-30 ℃ to 60 ℃ (-22 ℉ to 140 ℉), Humidity: ≤ 95% RH (non-condensing) |
| Surge Protection |
4 KV |
| Reset Button |
Support |
| Web Client Language |
20 Languages: Traditional Chinese, English, Simplified Chinese, Polish, German, Russian, French, Korean, Dutch, Czech, Portuguese (Europe), Portuguese (Brazil), Japanese, Thai, Turkish, Spanish (Latin America), Spanish (Europe), Hungarian, Italian, Vietnamese |
| RTC |
Support |
